Ramo-Y pillar table

"Pillar tables"

The versatile Ramo pedestal table family includes RamoY, available as standard in two heights. At a height of 730 mm, the table comes in standard sizes ranging from 1200x800 to 2400x1000 mm. This table model can easily be customised to accommodate more seating. You can choose from four surface materials and customise the table with any NCS colour to create a unique design. RamoY combines elegant form with functionality, making it perfect for both private and public spaces. The pedestal of these tables is made entirely of solid wood, a renewable resource.

5 years warranty and 10 years spare part guarantee.

DIMENSIONS (MM) & NUMBER OF SEATS

1200x800/900/1000, h730: 2 chair/side
1400x800/900/1000, h730: 2 chair/side
1800x800/900/1000, h730: 2 chair/side
2400x800/900/1000, h730: 2 chair/side
Different size than standard
Annan storlek än std

Surface material plate

Thin veneer ash, 1.5 mm
Thin veneer birch, 1.5 mm
Thin veneer oak, 1.5 mm
Thin veneer ash 1.5 mm, White 16
Thin veneer BARK, Brown nature 08 (wax)
HPL laminate, Natural ash F8843
HPL laminate, Birch F7129
HPL laminate, Elegant oak F5374
HPL laminate, Alpino F1040
HPL laminate, Silver F2791
HPL laminate, Folkstone F7927
HPL laminate, Pumice F7858
Fenix laminate, Nero 0720
Fenix laminate, Verde Comodoro 0750
Fenix laminate, Rosso Jaipur 0751
Linoleum, Mushroom 4176
Linoleum, Nero 4023
Linoleum, Smokey Blue 4179
Linoleum, Pistachio 4183
Linoleum, Burgundy 4154
Kayar, natural rubber, K54 - gray beige
Kayar, natural rubber, K21 - gray blue
Other surface material than standard

Wood species base

Ash, clear lacquer no.10
Birch, clear lacquer no.10
Oak, clear lacquer no.11
White 16B
BARK, Brown nature 08 (wax)
Black, S9000
SKY S7010-R90B
SEA S7010-B30G
FOREST S7010-G30Y
TRADITION, S7010-Y90R
CHILD, S5030-Y80R
SHADOW, S7000-N
FOG, S4000-N
CLAY, S4005-Y20R
BARK S7005-Y20R
AIR, S3010-B
Other wood species than standard

Ramo-Y pillar table

The Ramo table family is created by the skilled design duo O4i Design Studio and stands out with its elegant and functional design. RamoY at 730 mm height, like the other models in the series, is designed with sturdy pedestals that utilise the natural strength of wood to create stable and durable tables. Every detail is carefully crafted to highlight the precision of the workmanship. The table is a flexible solution that suits a wide range of interior environments.

For a complete solution in terms of comfort and functionality, we recommend combining RamoY with the Tova-S chair. This wooden chair can easily be hung under the tabletop, simplifying cleaning. RamoY can also be equipped with electrical solutions for added convenience.

RamoY is also available in a taller variant at 900 mm and can be combined with smaller tabletops, such as through RamoT, for additional variation and flexibility.

OPEN ALL

Product specifications & construction

Table certified with Möbelfakta and Environmental Product Declaration (EPD). Frameless wooden pillar table with a branching base made entirely of solid wood. Designed for glue-free assembly and built for a circular lifecycle. The pillar table features a distinct and elegant profile, offering free seating around the table.

The tabletop core is a reworkable 24 mm environmentally certified birch plywood. The seamless surface of the tabletop is covered with re-sandable 1.5 mm thick veneer/HPL/DT Linoleum/Kayar/Custom selection. The underside of the tabletop is pre-drilled and equipped with M6 inserts for easy attachment and removal of legs to facilitate reuse and circularity.

The table edge has exposed birch plywood to reduce the number of material types. The edge has a rounded 7 mm radius and a 35 mm bevel for a soft design (Rectangular table corners with R7 radius).

The pillar base is made of solid wood, with an organic Ø90 mm shape that branches into four legs, each 40 mm thick, angled at 45 degrees. Footprint sizes: large 950 mm / medium 745 mm. Integrated adjustable foot gliders for stability on the floor.

A concealed metal bracket under the tabletop, RAL 9003, and a hidden bent reinforcement plate in the branching base ensure durability. All metal is attached without glue.

The metal bracket is mounted glue-free on the tabletop using bolts for easy assembly/disassembly into pre-installed M6 inserts.

Dismantlable with hand tools, allowing reassembly after refurbishment or part replacement while maintaining function and stability. The free clearance from floor to the underside of the tabletop is >700 mm. The table comes with a 5-year warranty and a 10-year spare parts guarantee.

Assembly/disassembly manual
See files below

Emissions, sustainability certifications, and agreements

CO2 emissions per kg product (kg CO2-eq./kg): 2.1
Total climate impact of the analysed product (kg CO2-eq./product): 32.9
(Reviewed product: RamoX Pillar Table, Diameter 800 mm, 1.5 mm ash veneer, undercarriage H730 in ash.)
Reconditioning: Excellent for reconditioning
Eco-label Type 1: Not currently certified with Möbelfakta but meets Möbelfakta standards and will be certified shortly.
Eco-label Type 3:Environmental Product Declaration
(Reviewed product: RamoX Pillar Table, Diameter 800 mm, 1.5 mm ash veneer, undercarriage H730 in ash.)

Spare parts

Spare parts are available
Contact us

Assembly/disassembly manual
See files below

Reconditioning

Reconditioning - Good for reconditioning (means that the table is easy to disassemble into parts but that different material types cannot be separated easily).
